CESNET2: IP/MPLS backbone utilization Link: Brno → Lednice - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Brno" to "Lednice" measured at "Brno" , "input bitrate" presents traffic going from "Lednice" to "Brno" " measured at "Brno" - all time values are in MEST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Sat May 10 00:00:00 2025 ... Sat May 10 23:59:59 2025 (2025-05-10 00:00:00 till 2025-05-10 23:59:59) |
| 2025-05-10 00:00:00 - 2025-05-10 23:59:59 |
| Bit rates [bps] |
Input |
min=160.151M | |
max=377.010M | |
avr=246.766M | |
Output |
min=24.972M | |
max=218.706M | |
avr=71.275M | |
| 2025-05-10 00:00:00 ... 2025-05-10 23:59:59 ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__2025-05-10-00-00-00_2025-05-10-23-59-59_auto_8cb9891aeaa00025ad62e6c4bde7f7c6.png) |
|
Packet rates [pps] |
Input |
min=15.189k | |
max=36.522k | |
avr=25.276k | |
Output |
min=9.053k | |
max=41.034k | |
avr=16.881k | |
| 2025-05-10 00:00:00 ... 2025-05-10 23:59:59 ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__2025-05-10-00-00-00_2025-05-10-23-59-59_auto_8707a47723108b7ac9b2a29ff5088598.png) |
|
View: IP/MPLS aggregated utilization |
|
|
