CESNET3: IP/MPLS backbone utilization
Link: Brno → Vyškov
  • traffic directions in graphs follow the network interface perspective - for example:
    "output bitrate" presents traffic going from "Brno" to "Vyškov" measured at "Brno" ,
    "input bitrate" presents traffic going from "Vyškov" to "Brno" " measured at "Brno"
  • all time values are in FST (Europe/Prague), GMT+2H
Back to map CESNET a.l.e. - homepage
Sat May 31 00:00:00 2025 ... Sat May 31 23:59:59 2025 (2025-05-31 00:00:00 till 2025-05-31 23:59:59)
2025-05-31 00:00:00  -  2025-05-31 23:59:59
Bit rates  [bps]
Input
     min=1.548M
     max=46.744M
     avr=16.730M
Output
     min=6.159M
     max=1.348G
     avr=61.884M
 2025-05-31 00:00:00 ... 2025-05-31 23:59:59
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=749.390
     max=11.823k
     avr=3.258k
Output
     min=1.228k
     max=112.860k
     avr=6.517k
 2025-05-31 00:00:00 ... 2025-05-31 23:59:59
[Interfaces]: Packet rates
View: IP/MPLS aggregated utilization
