CESNET3: IP/MPLS backbone utilization
Link: Brno → Vyškov
  • traffic directions in graphs follow the network interface perspective - for example:
    "output bitrate" presents traffic going from "Brno" to "Vyškov" measured at "Brno" ,
    "input bitrate" presents traffic going from "Vyškov" to "Brno" " measured at "Brno"
  • all time values are in FST (Europe/Prague), GMT+2H
Back to map CESNET a.l.e. - homepage
Sat Jun 28 00:00:00 2025 ... Sat Jun 28 23:59:59 2025 (2025-06-28 00:00:00 till 2025-06-28 23:59:59)
2025-06-28 00:00:00  -  2025-06-28 23:59:59
Bit rates  [bps]
Input
     min=998.423k
     max=71.252M
     avr=11.637M
Output
     min=2.679M
     max=200.881M
     avr=36.044M
 2025-06-28 00:00:00 ... 2025-06-28 23:59:59
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=565.213
     max=10.102k
     avr=2.331k
Output
     min=683.895
     max=17.185k
     avr=3.808k
 2025-06-28 00:00:00 ... 2025-06-28 23:59:59
[Interfaces]: Packet rates
View: IP/MPLS aggregated utilization
