CESNET3: IP/MPLS backbone utilization
Link: Ostrava → Opava
  • traffic directions in graphs follow the network interface perspective - for example:
    "output bitrate" presents traffic going from "Ostrava" to "Opava" measured at "Ostrava" ,
    "input bitrate" presents traffic going from "Opava" to "Ostrava" " measured at "Ostrava"
  • all time values are in FST (Europe/Prague), GMT+2H
Back to map CESNET a.l.e. - homepage
Thu Sep 11 00:00:00 2025 ... Thu Sep 11 23:59:59 2025 (2025-09-11 00:00:00 till 2025-09-11 23:59:59)
2025-09-11 00:00:00  -  2025-09-11 23:59:59
Bit rates  [bps]
Input
     min=3.611M
     max=1.255G
     avr=108.711M
Output
     min=12.098M
     max=1.552G
     avr=208.627M
 2025-09-11 00:00:00 ... 2025-09-11 23:59:59
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=1.030k
     max=101.433k
     avr=13.510k
Output
     min=1.831k
     max=133.739k
     avr=22.254k
 2025-09-11 00:00:00 ... 2025-09-11 23:59:59
[Interfaces]: Packet rates
View: IP/MPLS aggregated utilization
