CESNET3: IP/MPLS backbone utilization
Link: Brno → Vyškov
  • traffic directions in graphs follow the network interface perspective - for example:
    "output bitrate" presents traffic going from "Brno" to "Vyškov" measured at "Brno" ,
    "input bitrate" presents traffic going from "Vyškov" to "Brno" " measured at "Brno"
  • all time values are in MET DST (Europe/Prague), GMT+2H
Back to map CESNET a.l.e. - homepage
Thu Sep 18 00:00:00 2025 ... Thu Sep 18 23:59:59 2025 (2025-09-18 00:00:00 till 2025-09-18 23:59:59)
2025-09-18 00:00:00  -  2025-09-18 23:59:59
Bit rates  [bps]
Input
     min=42.861M
     max=284.705M
     avr=68.257M
Output
     min=19.445M
     max=983.429M
     avr=314.038M
 2025-09-18 00:00:00 ... 2025-09-18 23:59:59
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=4.990k
     max=43.035k
     avr=15.039k
Output
     min=3.024k
     max=93.970k
     avr=31.008k
 2025-09-18 00:00:00 ... 2025-09-18 23:59:59
[Interfaces]: Packet rates
View: IP/MPLS aggregated utilization
