CESNET2: IP/MPLS backbone utilization
Link: České Budějovice → Brno
  • traffic directions in graphs follow the network interface perspective - for example:
    "output bitrate" presents traffic going from "České Budějovice" to "Brno" measured at "České Budějovice" ,
    "input bitrate" presents traffic going from "Brno" to "České Budějovice" " measured at "České Budějovice"
  • all time values are in CEST (Europe/Prague), GMT+2H
Back to map CESNET a.l.e. - homepage
Sun Oct 22 20:22:45 2017 ... Sun Apr 22 20:22:45 2018 (-1 day, -1 week, -6 months till now)

-1 day

Bit rates  [bps]
Input
     min=15.698k
     max=16.644k
     avr=16.109k
Output
     min=14.706k
     max=15.679k
     avr=15.139k
 -1 day
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=23.407
     max=24.280
     avr=23.873
Output
     min=22.334
     max=23.277
     avr=22.778
 -1 day
[Interfaces]: Packet rates


-1 week

Bit rates  [bps]
Input
     min=15.606k
     max=95.067M
     avr=101.424k
Output
     min=14.523k
     max=4.481M
     avr=19.050k
 -1 week
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=23.407
     max=8.056k
     avr=31.082
Output
     min=22.056
     max=933.883
     avr=23.402
 -1 week
[Interfaces]: Packet rates


-6 months

Bit rates  [bps]
Input
     min=15.401k
     max=2.042G
     avr=1.139M
Output
     min=14.523k
     max=2.233G
     avr=970.898k
 -6 months
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=21.305
     max=178.620k
     avr=129.504
Output
     min=20.285
     max=215.404k
     avr=165.501
 -6 months
[Interfaces]: Packet rates
View: IP/MPLS aggregated utilization
