CESNET2: IP/MPLS backbone utilization
Link: České Budějovice → Jindřichův Hradec
  • traffic directions in graphs follow the network interface perspective - for example:
    "output bitrate" presents traffic going from "České Budějovice" to "Jindřichův Hradec" measured at "České Budějovice" ,
    "input bitrate" presents traffic going from "Jindřichův Hradec" to "České Budějovice" " measured at "České Budějovice"
  • all time values are in MEST (Europe/Prague), GMT+2H
Back to map CESNET a.l.e. - homepage
Thu Mar 22 12:53:25 2018 ... Sat Sep 22 12:53:25 2018 (-1 day, -1 week, -6 months till now)

-1 day

Bit rates  [bps]
Input
     min=306.691k
     max=7.136M
     avr=1.237M
Output
     min=540.818k
     max=46.938M
     avr=12.432M
 -1 day
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=112.081
     max=2.420k
     avr=653.418
Output
     min=216.354
     max=4.288k
     avr=1.350k
 -1 day
[Interfaces]: Packet rates


-1 week

Bit rates  [bps]
Input
     min=235.549k
     max=130.324M
     avr=2.958M
Output
     min=220.875k
     max=389.250M
     avr=27.455M
 -1 week
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=83.356
     max=14.180k
     avr=1.286k
Output
     min=184.093
     max=33.013k
     avr=2.752k
 -1 week
[Interfaces]: Packet rates


-6 months

Bit rates  [bps]
Input
     min=85.674k
     max=226.586M
     avr=2.610M
Output
     min=103.552k
     max=600.691M
     avr=17.571M
 -6 months
[Interfaces]: Bit rates
Packet rates  [pps]
Input
     min=39.058
     max=22.547k
     avr=883.943
Output
     min=88.289
     max=51.573k
     avr=1.840k
 -6 months
[Interfaces]: Packet rates
View: IP/MPLS aggregated utilization
