CESNET3: IP/MPLS backbone utilization Link: Jihlava → Telč - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Jihlava" to "Telč" measured at "Jihlava" , "input bitrate" presents traffic going from "Telč" to "Jihlava" " measured at "Jihlava" - all time values are in MEST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Jan 15 22:55:19 2025 ... Tue Jul 15 22:55:19 2025 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=422.938k | |
max=945.445M | |
avr=11.093M | |
Output |
min=645.387k | |
max=828.753M | |
avr=32.790M | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_2de7e1fef31367ded59c67bf786800a8.png) |
|
Packet rates [pps] |
Input |
min=169.892 | |
max=142.722k | |
avr=2.345k | |
Output |
min=749.852 | |
max=71.632k | |
avr=4.945k | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_2e1a38139adf4fb0859a388b05e0927e.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=243.421k | |
max=947.845M | |
avr=6.885M | |
Output |
min=225.920k | |
max=843.722M | |
avr=25.610M | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_2de7e1fef31367ded59c67bf786800a8.png) |
|
Packet rates [pps] |
Input |
min=111.824 | |
max=143.125k | |
avr=1.567k | |
Output |
min=152.268 | |
max=73.511k | |
avr=4.367k | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_2e1a38139adf4fb0859a388b05e0927e.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=38.352k | |
max=2.169G | |
avr=4.131M | |
Output |
min=59.620k | |
max=1.908G | |
avr=14.449M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_2de7e1fef31367ded59c67bf786800a8.png) |
|
Packet rates [pps] |
Input |
min=52.330 | |
max=179.805k | |
avr=987.738 | |
Output |
min=83.581 | |
max=204.549k | |
avr=2.860k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_2e1a38139adf4fb0859a388b05e0927e.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
