CESNET3: IP/MPLS backbone utilization Link: Brno → Lednice - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Brno" to "Lednice" measured at "Brno" , "input bitrate" presents traffic going from "Lednice" to "Brno" " measured at "Brno" - all time values are in MET DST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Sun Mar 2 13:17:37 2025 ... Tue Sep 2 13:17:37 2025 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=191.569M | |
max=360.423M | |
avr=262.252M | |
Output |
min=7.735M | |
max=170.188M | |
avr=41.555M | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_8cb9891aeaa00025ad62e6c4bde7f7c6.png) |
|
Packet rates [pps] |
Input |
min=19.032k | |
max=35.976k | |
avr=25.879k | |
Output |
min=8.668k | |
max=25.312k | |
avr=13.551k | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_8707a47723108b7ac9b2a29ff5088598.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=107.645M | |
max=465.933M | |
avr=264.654M | |
Output |
min=7.735M | |
max=720.767M | |
avr=45.314M | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_8cb9891aeaa00025ad62e6c4bde7f7c6.png) |
|
Packet rates [pps] |
Input |
min=15.573k | |
max=49.741k | |
avr=26.142k | |
Output |
min=6.943k | |
max=71.572k | |
avr=14.060k | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_8707a47723108b7ac9b2a29ff5088598.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=749.764k | |
max=994.417M | |
avr=241.639M | |
Output |
min=695.892k | |
max=1.063G | |
avr=71.293M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_8cb9891aeaa00025ad62e6c4bde7f7c6.png) |
|
Packet rates [pps] |
Input |
min=373.212 | |
max=102.206k | |
avr=24.686k | |
Output |
min=426.403 | |
max=98.550k | |
avr=15.050k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_8707a47723108b7ac9b2a29ff5088598.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
