CESNET2: IP/MPLS backbone utilization Link: České Budějovice → Plzeň - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "České Budějovice" to "Plzeň" measured at "České Budějovice" , "input bitrate" presents traffic going from "Plzeň" to "České Budějovice" " measured at "České Budějovice" - all time values are in MEST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Feb 9 05:56:46 2022 ... Tue Aug 9 05:56:46 2022 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=20.001k | |
max=21.553k | |
avr=20.491k | |
Output |
min=19.931k | |
max=21.431k | |
avr=20.429k | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_21d1ca08cded536c8da1fcdd1782f790.png) |
|
Packet rates [pps] |
Input |
min=26.625 | |
max=30.391 | |
avr=29.690 | |
Output |
min=26.470 | |
max=30.305 | |
avr=29.602 | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_0f736735ff6c097635585612649ae9a3.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=19.196k | |
max=54.752k | |
avr=20.500k | |
Output |
min=19.128k | |
max=21.568k | |
avr=20.434k | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_21d1ca08cded536c8da1fcdd1782f790.png) |
|
Packet rates [pps] |
Input |
min=25.166 | |
max=38.895 | |
avr=29.699 | |
Output |
min=25.103 | |
max=30.459 | |
avr=29.602 | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_0f736735ff6c097635585612649ae9a3.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=16.667k | |
max=4.634G | |
avr=5.700M | |
Output |
min=16.559k | |
max=9.211G | |
avr=12.900M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_21d1ca08cded536c8da1fcdd1782f790.png) |
|
Packet rates [pps] |
Input |
min=23.837 | |
max=569.961k | |
avr=830.174 | |
Output |
min=23.899 | |
max=898.433k | |
avr=1.317k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_0f736735ff6c097635585612649ae9a3.png) |
|
