CESNET2/3: IP/MPLS backbone utilization Link: Liberec → Ústí nad
Labem - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Liberec" to "Ústí nad
Labem" measured at "Liberec" , "input bitrate" presents traffic going from "Ústí nad
Labem" to "Liberec" " measured at "Liberec" - all time values are in SST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Nov 30 18:40:16 2022 ... Tue May 30 18:40:16 2023 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=100.527k | |
max=157.641k | |
avr=125.436k | |
Output |
min=100.350k | |
max=157.081k | |
avr=125.226k | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_7e5b01634de3bc58fefeb09789c4f1a8.png) |
|
Packet rates [pps] |
Input |
min=155.731 | |
max=270.112 | |
avr=201.059 | |
Output |
min=155.443 | |
max=269.290 | |
avr=200.522 | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_ddeeaa45ff6317672d293da7429714d0.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=93.141k | |
max=168.971k | |
avr=125.486k | |
Output |
min=93.456k | |
max=166.890k | |
avr=125.187k | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_7e5b01634de3bc58fefeb09789c4f1a8.png) |
|
Packet rates [pps] |
Input |
min=116.696 | |
max=270.112 | |
avr=200.942 | |
Output |
min=116.270 | |
max=269.290 | |
avr=200.470 | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_ddeeaa45ff6317672d293da7429714d0.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=64.656k | |
max=2.450G | |
avr=978.631k | |
Output |
min=66.978k | |
max=1.315G | |
avr=232.400k | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_7e5b01634de3bc58fefeb09789c4f1a8.png) |
|
Packet rates [pps] |
Input |
min=105.825 | |
max=244.531k | |
avr=292.290 | |
Output |
min=105.734 | |
max=146.707k | |
avr=232.429 | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_ddeeaa45ff6317672d293da7429714d0.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
