CESNET2: IP/MPLS backbone utilization Link: Olomouc → Zlín - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Olomouc" to "Zlín" measured at "Olomouc" , "input bitrate" presents traffic going from "Zlín" to "Olomouc" " measured at "Olomouc" - all time values are in MEST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Feb 9 06:11:28 2022 ... Tue Aug 9 06:11:28 2022 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=14.550k | |
max=4.215M | |
avr=50.274k | |
Output |
min=9.655M | |
max=238.272M | |
avr=75.363M | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_3d27f655671c7d64cf74acb9c7b7b1a7.png) |
|
Packet rates [pps] |
Input |
min=22.266 | |
max=397.764 | |
avr=37.902 | |
Output |
min=1.357k | |
max=24.662k | |
avr=8.763k | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_33f878b96d5f53dba010644d0d6a22c3.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=12.522k | |
max=5.726M | |
avr=55.147k | |
Output |
min=4.320M | |
max=358.362M | |
avr=60.528M | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_3d27f655671c7d64cf74acb9c7b7b1a7.png) |
|
Packet rates [pps] |
Input |
min=19.304 | |
max=561.858 | |
avr=38.524 | |
Output |
min=903.491 | |
max=35.235k | |
avr=6.994k | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_33f878b96d5f53dba010644d0d6a22c3.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=11.348k | |
max=727.011M | |
avr=8.444M | |
Output |
min=12.259k | |
max=1.884G | |
avr=141.788M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_3d27f655671c7d64cf74acb9c7b7b1a7.png) |
|
Packet rates [pps] |
Input |
min=14.309 | |
max=117.509k | |
avr=2.366k | |
Output |
min=18.233 | |
max=448.265k | |
avr=16.223k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_33f878b96d5f53dba010644d0d6a22c3.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
