CESNET3: IP/MPLS backbone utilization Link: Plzeň → Most - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Plzeň" to "Most" measured at "Plzeň" , "input bitrate" presents traffic going from "Most" to "Plzeň" " measured at "Plzeň" - all time values are in MET DST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Jan 1 21:54:59 2025 ... Tue Jul 1 21:54:59 2025 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=97.298k | |
max=671.507k | |
avr=172.865k | |
Output |
min=98.742k | |
max=6.811M | |
avr=244.103k | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_6197d235f9a09d55b643ed50f897eb7f.png) |
|
Packet rates [pps] |
Input |
min=102.935 | |
max=497.567 | |
avr=173.415 | |
Output |
min=123.892 | |
max=748.709 | |
avr=186.235 | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_62ff235eb5c07a96844c7b6478639aa4.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=77.552k | |
max=1.108M | |
avr=181.764k | |
Output |
min=89.582k | |
max=25.144M | |
avr=366.000k | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_6197d235f9a09d55b643ed50f897eb7f.png) |
|
Packet rates [pps] |
Input |
min=73.906 | |
max=1.175k | |
avr=178.917 | |
Output |
min=71.522 | |
max=3.939k | |
avr=199.625 | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_62ff235eb5c07a96844c7b6478639aa4.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=190.246 | |
max=39.864M | |
avr=129.060k | |
Output |
min=206.248 | |
max=380.134M | |
avr=963.599k | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_6197d235f9a09d55b643ed50f897eb7f.png) |
|
Packet rates [pps] |
Input |
min=240.906m | |
max=8.095k | |
avr=155.834 | |
Output |
min=245.478m | |
max=44.889k | |
avr=271.780 | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_62ff235eb5c07a96844c7b6478639aa4.png) |
|
