CESNET2: IP/MPLS backbone utilization Link: Plzeň → Praha - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Plzeň" to "Praha" measured at "Plzeň" , "input bitrate" presents traffic going from "Praha" to "Plzeň" " measured at "Plzeň" - all time values are in FWT (Europe/Prague), GMT+1H
| Back to map |
 |
|
Tue Jul 28 12:59:45 2020 ... Thu Jan 28 12:59:45 2021 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=425.730M | |
max=5.080G | |
avr=1.956G | |
Output |
min=139.549M | |
max=4.794G | |
avr=1.063G | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_aa9173771cccf49f9377d5a8a0489f3c.png) |
|
Packet rates [pps] |
Input |
min=68.865k | |
max=533.150k | |
avr=231.401k | |
Output |
min=51.375k | |
max=501.759k | |
avr=173.610k | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_44e85a9935e00f81b9bb481756ffad4a.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=226.879M | |
max=14.667G | |
avr=2.018G | |
Output |
min=19.517M | |
max=4.794G | |
avr=841.549M | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_aa9173771cccf49f9377d5a8a0489f3c.png) |
|
Packet rates [pps] |
Input |
min=23.621k | |
max=599.599k | |
avr=230.415k | |
Output |
min=8.964k | |
max=501.759k | |
avr=149.152k | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_44e85a9935e00f81b9bb481756ffad4a.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=17.113k | |
max=30.799G | |
avr=2.067G | |
Output |
min=15.683k | |
max=11.925G | |
avr=818.175M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_aa9173771cccf49f9377d5a8a0489f3c.png) |
|
Packet rates [pps] |
Input |
min=25.075 | |
max=1.133M | |
avr=240.833k | |
Output |
min=23.496 | |
max=1.053M | |
avr=154.912k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_44e85a9935e00f81b9bb481756ffad4a.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
