CESNET2: IP/MPLS backbone utilization Link: Ústí nad
Labem → Děčín - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Ústí nad
Labem" to "Děčín" measured at "Ústí nad
Labem" , "input bitrate" presents traffic going from "Děčín" to "Ústí nad
Labem" " measured at "Ústí nad
Labem" - all time values are in FWT (Europe/Prague), GMT+1H
| Back to map |
 |
|
Tue Jul 28 12:34:33 2020 ... Thu Jan 28 12:34:33 2021 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=330.374k | |
max=7.668M | |
avr=887.633k | |
Output |
min=787.529k | |
max=471.802M | |
avr=8.832M | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_a0c02bcdb226c8259aa44fa170063ac1.png) |
|
Packet rates [pps] |
Input |
min=231.734 | |
max=8.002k | |
avr=597.198 | |
Output |
min=283.046 | |
max=40.508k | |
avr=1.158k | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_96bc7a3c5a6d8055041e1fc1e4b68225.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=330.374k | |
max=95.814M | |
avr=1.405M | |
Output |
min=557.643k | |
max=693.306M | |
avr=10.721M | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_a0c02bcdb226c8259aa44fa170063ac1.png) |
|
Packet rates [pps] |
Input |
min=230.249 | |
max=9.139k | |
avr=723.605 | |
Output |
min=283.046 | |
max=55.578k | |
avr=1.340k | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_96bc7a3c5a6d8055041e1fc1e4b68225.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=51.015k | |
max=863.681M | |
avr=3.135M | |
Output |
min=71.972k | |
max=752.291M | |
avr=11.194M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_a0c02bcdb226c8259aa44fa170063ac1.png) |
|
Packet rates [pps] |
Input |
min=21.559 | |
max=72.155k | |
avr=869.474 | |
Output |
min=79.150 | |
max=67.597k | |
avr=1.368k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_96bc7a3c5a6d8055041e1fc1e4b68225.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
