CESNET2: IP/MPLS backbone utilization Link: Ústí nad
Labem → Most - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Ústí nad
Labem" to "Most" measured at "Ústí nad
Labem" , "input bitrate" presents traffic going from "Most" to "Ústí nad
Labem" " measured at "Ústí nad
Labem" - all time values are in MEST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Feb 9 06:08:16 2022 ... Tue Aug 9 06:08:16 2022 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=6.937k | |
max=975.623k | |
avr=40.591k | |
Output |
min=4.986k | |
max=8.299M | |
avr=211.508k | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_0484997815d7e9f9266454da1ea3be27.png) |
|
Packet rates [pps] |
Input |
min=7.323 | |
max=435.233 | |
avr=21.842 | |
Output |
min=5.877 | |
max=873.136 | |
avr=34.867 | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_652d10f29b64b43273234e3366bc30c2.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=6.060k | |
max=5.947M | |
avr=38.781k | |
Output |
min=4.124k | |
max=54.416M | |
avr=181.899k | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_0484997815d7e9f9266454da1ea3be27.png) |
|
Packet rates [pps] |
Input |
min=6.283 | |
max=938.506 | |
avr=19.882 | |
Output |
min=5.314 | |
max=8.292k | |
avr=34.878 | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_652d10f29b64b43273234e3366bc30c2.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=3.961k | |
max=32.670M | |
avr=59.494k | |
Output |
min=4.084k | |
max=365.089M | |
avr=355.790k | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_0484997815d7e9f9266454da1ea3be27.png) |
|
Packet rates [pps] |
Input |
min=4.245 | |
max=19.116k | |
avr=34.602 | |
Output |
min=4.142 | |
max=32.437k | |
avr=48.128 | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_652d10f29b64b43273234e3366bc30c2.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
