CESNET2: IP/MPLS backbone utilization Link: Ústí nad
Labem → Praha - traffic directions in graphs follow the network interface perspective - for example:
"output bitrate" presents traffic going from "Ústí nad
Labem" to "Praha" measured at "Ústí nad
Labem" , "input bitrate" presents traffic going from "Praha" to "Ústí nad
Labem" " measured at "Ústí nad
Labem" - all time values are in MEST (Europe/Prague), GMT+2H
| Back to map |
 |
|
Wed Feb 9 06:42:21 2022 ... Tue Aug 9 06:42:21 2022 (-1 day, -1 week, -6 months till now) |
| -1 day |
| Bit rates [bps] |
Input |
min=107.765M | |
max=2.670G | |
avr=1.091G | |
Output |
min=15.341M | |
max=1.228G | |
avr=236.769M | |
| -1 day ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-day_now_auto_a110a1a96dbc8901a37f0b278a51f040.png) |
|
Packet rates [pps] |
Input |
min=13.785k | |
max=250.426k | |
avr=107.958k | |
Output |
min=8.249k | |
max=166.808k | |
avr=52.628k | |
| -1 day ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-day_now_auto_b2d2ed8a553fa2fcf39ac5c78215f60b.png) |
|
|
| |
| -1 week |
| Bit rates [bps] |
Input |
min=96.291M | |
max=2.670G | |
avr=634.643M | |
Output |
min=12.129M | |
max=1.289G | |
avr=164.857M | |
| -1 week ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-1-week_now_auto_a110a1a96dbc8901a37f0b278a51f040.png) |
|
Packet rates [pps] |
Input |
min=10.963k | |
max=250.426k | |
avr=66.750k | |
Output |
min=5.827k | |
max=170.896k | |
avr=39.446k | |
| -1 week ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-1-week_now_auto_b2d2ed8a553fa2fcf39ac5c78215f60b.png) |
|
|
| |
| -6 months |
| Bit rates [bps] |
Input |
min=53.066M | |
max=3.852G | |
avr=714.218M | |
Output |
min=12.129M | |
max=1.870G | |
avr=213.287M | |
| -6 months ![[Interfaces]: Bit rates](index_INTERFACE_bitrates__-6-months_now_auto_a110a1a96dbc8901a37f0b278a51f040.png) |
|
Packet rates [pps] |
Input |
min=6.590k | |
max=14.031M | |
avr=77.093k | |
Output |
min=4.182k | |
max=4.321G | |
avr=108.221k | |
| -6 months ![[Interfaces]: Packet rates](index_INTERFACE_pktrates__-6-months_now_auto_b2d2ed8a553fa2fcf39ac5c78215f60b.png) |
|
View: IP/MPLS aggregated utilization |
|
| |
|
